1: Product Keywords:

LiFePO4, Ultra-high Capacity, High Energy Density, Long Lifespan, Commercial and Industrial Energy Storage.

2: Introduction:

The 314 Series LiFePO4 Battery Cell is an upgraded version of the 280 series, offering higher capacity and energy density. It maintains all the advantages of LiFePO4 technology while providing larger storage capacity in a similar footprint, suitable for applications requiring higher energy density.

3: Flow Chart:

Raw Material Preparation → Electrode Manufacturing → Cell Assembly → Formation → Aging → Performance Testing → Sorting and Packaging

4: Technical Specifications:

• Dimensions: Approx. 173mm x 71mm x 314mm (exact dimensions may vary slightly).

• Capacity: 314Ah.

• Nominal Voltage: 3.2V.

• Energy Density: >170Wh/kg.

• Cycle Life: >6000 cycles (80% DOD).

• Operating Temperature: -20°C to 55°C.

5: Technical Features:

• Ultra-high capacity, larger energy storage per unit volume.

• Higher energy density, providing longer endurance.

• Excellent cycle performance, suitable for frequent charge-discharge applications.

• Superior thermal stability, enhanced safety performance.

• Low self-discharge rate, excellent long-term storage performance.

• Fast charging and discharging capability, supporting higher rate applications.

• Excellent consistency, beneficial for large-scale battery assembly.

• Better low-temperature performance, adapting to a wider range of environmental conditions.

• High reliability, suitable for long-term operation in critical applications.

6: Application:

• Large-scale commercial and industrial energy storage systems.

• Grid-scale energy storage projects.

• Large-scale renewable energy storage.

• Data center backup power systems.

• Electric heavy-duty vehicles.

• Marine and offshore engineering energy storage.

• Smart microgrid systems.

• High-end power tools and equipment.
