Automated assembly line, cylindrical battery production, laser welding, energy storage.

2:Introduction:

This production line is mainly used for the back-end application process of 32135/40140 cylindrical lithium batteries. Key processes include cell sorting, automatic AI polarity detection, automatic welding, automatic flipping, automatic transfer, manual assembly, and comprehensive testing. The front section of the line completes module PACK welding and previous processes through module integration and speed chains, while the back section mainly uses manually operated speed chains.

3: Technical Specifications:

• Dimensions: Total length approx. 27 meters, total width approx. 7.0 meters (Small cylindrical assembly line: 9.3m long, 2.1m wide).

• Single Machine Qualification Rate: ≥99%.

• Voltage: 380V±5%, 50Hz.

• Power Capacity: >50Kw.

• Air Pressure Requirement: 260L/min, 0.5-0.8MPa.

4:Technical Features:

High degree of automation, high compatibility, high precision, and fast speed

Automated production, reduced manual positions, high overall production efficiency

Customizable automated production line solutions according to customer needs

Flexible adaptation to specific customer requirements.

5: Application:

New energy vehicle battery production, energy storage system battery production.
