1: Keywords:

Slitting machine, battery material processing, precision slitting.

2: Process Flow:

• Single-shaft Winding → Splicing and Handling → Tension Isolation → Electrode Slitting

• From Electrode Slitting, it branches into two parallel processes:

Branch 1: Width Inspection → Dust and Iron Removal → Single-shaft Winding

Branch 2: Width Inspection → Dust and Iron Removal → Single-shaft Winding

erials.

3: Technical specifications:

• Suitable material width: 700mm

• Production speed: 30~100m/min

• Unwinding roll diameter: 600mm~1000mm

• Rewinding roll diameter: 600mm~750mm

• Slitting width precision: ±0.3mm (with CCD width measurement)

• Alignment accuracy: 0.5mm

• Unwinding tension control precision: ±5N

3:Technical Features:

• High-precision slitting.

• Optional CCD width measurement and process alignment closed-loop control.

• Unwinding with speed closed-loop and tension closed-loop control.

• Upper blade can be configured with individually driven electronic knives for quick and easy blade changes.

• High alignment accuracy.

4: Application:

Battery material production (can be used for slitting positive or negative electrode materials).
