1: Keywords:

Positive electrode, roll pressing, slitting, integrated machine

2: Process Flow:

Single Acceptance  ->  Acceptance Screening ->  Risk Assessment ->  Application ->  Mainframe

Single Acceptance  ->  Acceptance Screening ->  Review  ->  Application  ->  Mainframe ->  Environmental Control

3: Technical specifications:

• Suitable material width: 1100mm

• Production speed: 80~150m/min

• Unwinding roll diameter: 1000mm~1300mm

• Rewinding roll diameter: 1000mm

• Splicing success rate: 95~99%

• Roll pressing precision: ±0.002mm

• Unwinding tension control precision: ±5N

• Stretching tension control precision: ±5N

• Rolling roll precision: ±0.001mm (cylindricity, straightness, etc.)

4: Technical Features:

• Integrated roll pressing and slitting design.

• High-precision roll pressing.

• Optional pressure closed-loop and roll gap closed-loop control.

• Unwinding with speed closed-loop and tension closed-loop control.

• High-precision stretching tension control.

• Special surface treatment for rolling rolls (chrome-plated or tungsten carbide).

5: Application:

Battery positive electrode material production.
